1.Technical parameter

Material
Pin header: Brass, Tin plated
Housing: PA66, UL94V-0

Electrical
Rated voltage: 300V
Rated current: 10A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ/1000V
Withstanding Voltage: AC1500V/1Min
Wire range: 22-16AWG 1.5MM²

Mechanical
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Strip length: 10m


2.Datasheet of spring terminal block 142R

datasheet of spring temrinal block

3.Picture of spring clamp termina block 142R

China exporter&supplier of 22-16AWG ROHS spring clamp terminal block pitch7.5/7.62mm

4.Package information, as follows,


Package boxes


packed them in the plastic bag

5.How to order

Shippment
1:Usually we ship your order by sea or by air . ..
2:We'll tell you the shipping status once your order has been sent.

Package
1:Inner packing: plastic bag
2:Outer packing: Standard export carton

Payment
We accept Paypal ,Bank transfer ,Credit Card.etc.

Function

A terminal block is a set of two or more similar screw-down connection points. You can connect wires

at these points. A terminal strip combines many similar blocks in a single device. In a strip, the blocks are insulated from one another.

Materials

A terminal block's main functions are to connect and to insulate. The main block body is made of a tough material, such as plastic or ceramic, that electrically isolates adjacent blocks. The conducting parts are made of copper and corrosion-resistant metals compatible with copper.

Use

A terminal block must first be mounted in a safe, stable location away from moisture. To use it, strip

about ½ inch of insulation from the two wires you want to connect. You then insert the bare wires into the block's metal connectors and screw them down until they're securely fastened.

22-16AWG ROHS spring clamp terminal block pitch7.5/7.62mm

KF142R has been presented above.   It is good in quality and competitive in price. If you want more detailed information of this product or related problems, please contact with us, we will reply as soon as possible (general in 24 hours).
